Introduction

House of Orange is the famous heap technique for the program that never gives you a free(). Where almost every other house begins with the attacker freeing something, House of Orange manufactures a free chunk out of thin air by shrinking the top chunk: it overwrites the wilderness size with a smaller, page-aligned value, then makes an allocation larger than the (now small) top can satisfy. Forced to extend the heap, glibc’s sysmalloc frees the *old* top chunk into the unsorted bin — handing the attacker a free chunk without a single call to free. That free chunk is then leveraged with an unsorted-bin attack to write a libc pointer into _IO_list_all, and a forged _IO_FILE structure turns the next allocator abort into file-stream-oriented programming (FSOP) and code execution.

House of Orange (named for the challenge it debuted on) is the canonical chain that ties allocator internals to the _IO_FILE/FSOP world, and it is a story of layered mitigations. The classic end-to-end chain — top-shrink, unsorted-bin attack into _IO_list_all, fake FILE with a hijacked vtable — works on glibc up to and including 2.23. glibc 2.24 added vtable validation (_IO_vtable_check) that verifies a FILE’s vtable lies within the known __libc_IO_vtables region, breaking the naive vtable overwrite; and the unsorted-bin attack itself was killed around glibc 2.28–2.29 by a check that the unsorted list is consistent (bck->fd == victim). The technique therefore evolved — later FSOP variants (House of Orange with _IO_str_overflow, and ultimately House of Apple) route around the vtable check — but the top-shrink primitive at its core remains a textbook trick.

Attack Prerequisites

House of Orange trades the need for a free primitive for a specific overflow and a lot of glibc-internals knowledge. The classic chain needs:

  • A heap overflow into the top chunk’s size field — enough to overwrite the wilderness size with a smaller, carefully chosen value.
  • No free() primitive required — this is the technique’s signature; the free chunk is produced by sysmalloc extending the heap.
  • Control over allocation requests so you can ask for a size larger than the shrunk top, forcing the heap extension that frees the old top.
  • A libc leak (often obtained from the freed old-top chunk once it lands in the unsorted bin, whose fd/bk point into main_arena) to locate _IO_list_all and build the fake FILE.
  • glibc <= 2.23 for the classic chain; on 2.24+ the vtable check forces an FSOP variant, and on 2.28+ the unsorted-bin-attack write is itself blocked.

How It Works

The first primitive is the top-chunk shrink. When malloc cannot satisfy a request from bins or from the top chunk, it calls sysmalloc to grow the arena. Before extending, sysmalloc frees the *old* top chunk back into the unsorted bin — but only if the old top passes an assertion: its size must be at least MINSIZE, it must have PREV_INUSE set, and critically its end (old_top + old_size) must be page-aligned. House of Orange forges a top size that keeps the end page-aligned while being small enough that the next request overflows it, so the assertion holds and the old top is legitimately freed. The attacker now owns a free chunk in the unsorted bin — plus, because that chunk’s fd/bk are set to main_arena, a ready-made libc leak if the program prints the chunk.

The second primitive is the unsorted-bin attack. A chunk in the unsorted bin stores fd and bk pointers; when malloc later scans the unsorted bin, it unlinks the chunk with the classic operation bck = victim->bk; bin->fd = bck; bck->fd = bin; — writing the address of the unsorted-bin head (a libc address) to victim->bk + 0x10. By overwriting the freed old-top’s bk to &_IO_list_all - 0x10, the attacker makes that scan write a libc pointer into _IO_list_all, the global head of the linked list of open _IO_FILE streams. _IO_list_all now points into the unsorted bin — memory the attacker can shape.

The third primitive is FSOP. When glibc hits a fatal condition — or on normal exit — it walks the _IO_list_all chain and flushes each stream, calling function pointers out of each FILE’s vtable. Because _IO_list_all now points at attacker-controlled memory, the attacker lays out a fake _IO_FILE whose fields satisfy the flush path’s conditions and whose vtable pointer is redirected so that the flush call lands on system (or a one_gadget), with the FILE pointer arranged to double as a "/bin/sh" argument. On glibc <= 2.23 the vtable pointer can be aimed anywhere; glibc 2.24’s _IO_vtable_check constrains the vtable to the legitimate table region, which is why later variants pivot to functions like _IO_str_overflow/_IO_str_finish that live inside the validated vtables and can still be abused. The trigger is often deliberate: corrupting the heap so the *next* malloc aborts causes glibc’s error path to flush streams, firing the forged vtable call.

Vulnerable Code / Setup

The enabling bug is a heap overflow that reaches the top-chunk size, in a program that offers allocation and editing but *no* free. The overflow both shrinks the top and, on a later pass, plants the unsorted-bin bk:

#include <stdlib.h>
#include <string.h>

/* No free() is exposed. Only alloc + edit. The edit overflows into the
   top chunk header that sits after the last allocation. */
char *obj;

void setup(void) {
    obj = malloc(0x18);

    /* BUG: overflow past obj rewrites the top chunk size.
       Choose a value that keeps (top + new_size) page-aligned and small,
       e.g. 0x0fe1 on a fresh heap, so sysmalloc will free the old top. */
    char p[0x28];
    memset(p, 'A', 0x18);
    *(unsigned long *)(p + 0x18) = 0x0fe1;   /* shrunk, page-aligned end */
    memcpy(obj, p, 0x20);

    /* Request larger than the shrunk top -> sysmalloc frees old top into
       the unsorted bin (a free chunk with NO call to free). */
    malloc(0x1000);
}
C

The shrink value is not arbitrary: the old top’s end must stay page-aligned or sysmalloc‘s assertion fails. With the old top now in the unsorted bin, a second overflow plants the unsorted-bin-attack bk and forges the fake FILE. Triage confirms the version and whether the classic vtable overwrite applies:

$ checksec --file=./orange
RELRO      STACK CANARY   NX        PIE
Partial    Canary found   NX enab.  No PIE

$ ldd ./orange | grep libc   # <=2.23 classic; 2.24+ needs an FSOP variant
    libc.so.6 => /lib/x86_64-linux-gnu/libc.so.6 (2.23)
Bash

Walkthrough / Exploitation

Watch the top-shrink actually produce a freed chunk before building the FSOP stage — the presence of the old top in the unsorted bin is the checkpoint. In gdb with pwndbg:

gdb -q ./orange
pwndbg> run
pwndbg> top_chunk        # note top address + size before the overflow
pwndbg> # after overflow + the large malloc:
pwndbg> bins             # old top now sits in the unsorted bin
pwndbg> p (void*)&_IO_list_all   # target of the unsorted-bin attack
pwndbg> x/32gx <fake_file>       # inspect the forged _IO_FILE you build
Bash

The chain, in order: leak libc from the freed old-top; overwrite that chunk’s bk to &_IO_list_all - 0x10; forge a fake _IO_FILE in the same region with fields that pass the flush path and a redirected vtable; then trigger an allocator abort so glibc flushes streams through the forged vtable. A pwntools skeleton:

from pwn import *

io = process('./orange')
libc = ELF('./libc.so.6')

def alloc(sz, data=b''): ...   # menu wrappers (no free exposed)
def edit(data):          ...

# 1) shrink top -> large alloc -> old top freed into unsorted bin
edit(b'A'*0x18 + p64(0x0fe1))
alloc(0x1000)

# 2) read the freed chunk to leak a main_arena/libc address
libc.address = leak_libc() - libc.sym['main_arena'] - 0x60
io_list_all = libc.sym['_IO_list_all']
system      = libc.sym['system']

# 3) forge fake FILE: set bk=&_IO_list_all-0x10 (unsorted-bin attack),
#    craft _mode/_IO_write_ptr etc. so the flush path is entered, and
#    point the vtable so the flush call resolves to system('/bin/sh').
fake = build_fake_file(io_list_all, system, binsh=b'/bin/sh\x00')
edit(fake)

# 4) trigger: next malloc aborts -> glibc flushes streams -> vtable call
alloc(0x60)                    # error path fires the forged FILE
io.interactive()
Python

The escalation is the FSOP call itself: with _IO_list_all pointed at the forged FILE and the vtable redirected, the stream-flush that glibc performs on abort/exit calls system with the FILE pointer (arranged to begin with "/bin/sh"), yielding a shell. On glibc 2.24+ the same skeleton is retained but the vtable target is chosen from within the validated vtable region (e.g. abusing _IO_str_overflow), and on 2.28+ the unsorted-bin-attack write must be replaced by another way to control _IO_list_all, since that write primitive is blocked.

Note: The top-shrink is the load-bearing trick and its arithmetic is strict: the forged top size must leave old_top + size page-aligned, or sysmalloc‘s assertion aborts before the old top is freed. On a fresh main-arena heap the classic value is 0x0fe1 (top ends on the page boundary), but it depends on the current top address — compute it from the live top_chunk value in gdb rather than copying a constant.

Opsec: House of Orange is exquisitely version-bound. The pure vtable-overwrite ending works only up to glibc 2.23; 2.24 adds _IO_vtable_check and 2.28/2.29 kill the unsorted-bin-attack write with the ‘corrupted unsorted chunks’ consistency check. Fingerprint the libc first and pick the matching FSOP variant — a 2.23 chain aborts immediately on a 2.27+ target. Confirm each stage in gdb (bins after the shrink, _IO_list_all after the unsorted-bin attack) before wiring the trigger.

Detection and Defense

House of Orange chains a top-chunk overflow into allocator and FILE internals, so defenses span the overflow, the allocator checks, and the FSOP surface:

  • Keep glibc current — vtable validation (2.24+), the unsorted-bin consistency check (2.28/2.29), and later top-size sanity checks each remove a link of the classic chain.
  • Eliminate the top-chunk overflow — fortified copies and bounds checking stop the shrink that starts the whole technique.
  • Full RELRO + PIE + ASLR — force a libc leak (the technique needs _IO_list_all and system addresses) and remove static targets.
  • Harden the FILE surface — modern glibc’s _IO_vtable_check and pointer-guard mangling on some function pointers blunt naive FSOP; do not run pre-2.24 libc on exposed services.
  • Sanitizers in CI — AddressSanitizer catches the top-chunk heap overflow deterministically, well before it reaches sysmalloc.

Real-World Impact

House of Orange is one of the most influential heap write-ups in the exploitation canon: it popularised the top-chunk shrink, made the unsorted-bin attack widely understood, and was the on-ramp for a generation of researchers into _IO_FILE/FSOP exploitation. Its mitigations are equally instructive — the vtable check and the unsorted-bin consistency check are frequently cited as the reason later techniques (House of Apple, _IO_str_overflow chains) exist at all. While the exact classic chain is now a historical artifact on modern glibc, the primitives it introduced remain load-bearing in current exploitation, and the FSOP concept it demonstrated is central to defeating hardened, hook-free glibc where __malloc_hook/__free_hook no longer exist. It endures as the definitive lesson that allocator metadata and libc’s I/O structures are one continuous attack surface.

Conclusion

House of Orange is the heap technique for when there is no free: shrink the top chunk so that a large request forces sysmalloc to free the old top into the unsorted bin, leak libc from that chunk, use an unsorted-bin attack to point _IO_list_all at a forged _IO_FILE, and trigger an allocator abort so the stream flush executes your hijacked vtable. The classic end-to-end chain is a glibc-2.23 artifact — vtable validation and the unsorted-bin consistency check retired it — but the top-shrink primitive and the FSOP idea it introduced are permanent fixtures of heap exploitation, and its evolution into modern FSOP is the clearest map of how the allocator and libc’s I/O layer connect.
